Art. 9504 A2/CV 5,5X90 EPDM washer 16 mm
BI-Metal-Self drilling screws
Item number
95042B655 90
Materials
Bi-metal A2
EAN
3610500352645
Net weight per 100 pc.
1,500 kg
Item number
95042B655 90
Materials
Bi-metal A2
EAN
3610500352645
Net weight per 100 pc.
1,500 kg
- Technical data
- Product information
- Product Information Files
- Catalog page
Technical data
| Diameter (d) | 5,5 mm |
| Total length (l) | 90 mm |
| Drive size | SW 8 |
| Thread length (b) | 50 mm |
| Height of head (k) | 5,45 mm |
| Washer diameter (d3) | 16 mm |
Product information
Product benefits
- Drilling, shaping and joining in one step- Cut costs
- No tool changes, no drilling tools
Applications
- For steel profile sheet screw connections on steel substructures, and aluminium profile sheets and sandwich elements on aluminium or steel substructures from 1,5 mm to 5,0 mm- Recommended speed of processing:
1200-1800 U/min
Area of use
Metal construction, SolarFEATURES
- BI-Metal - a special welding process joins the stainless steel screw to the hardened carbon steel tip- Hex drive - an attractive solution for optimum power transmission
- Weatherproof - stainless steel sealing washer with vulcanised-on elastomer
Product Information Files
Share Art. 9504 A2/CV 5,5X90 EPDM washer 16 mm
