DIN 910 A2 M 26X1,5 according DIN 13
Hexagon head pipe plugs, metric fine pitch
Item number
0910226 15
Materials
A2
EAN
3610500090967
Net weight per 100 pc.
12,000 kg
Item number
0910226 15
Materials
A2
EAN
3610500090967
Net weight per 100 pc.
12,000 kg
- Technical data
- Product information
- Catalog page
Technical data
| Diameter (d) | 26 mm |
| Total length (l) | 30 mm |
| Corner measurement (e) | 26,17 mm |
| Drive shape (drive) | Outer hex |
| Drive size | SW 24 |
| strength class (Rm) | 500 N/mm² |
| Collar diameter (d2) | 31 mm |
| Measurement c (c) | 4 mm |
| Measurement m (m) | 10 mm |
Product information
Applications
Ideal for screw connections in the machine area.Area of use
Machine constructionShare DIN 910 A2 M 26X1,5 according DIN 13
